Product Code : VF--DCC-D192-CU
Caliber :DN100~DN400
Connection standard :PN10/16,ANS1150, DIN16,JIS10K, 16K
Working temperature :-15~85°C
Working pressure :PN0.1
Body material: carbon steel, cast aluminum alloy
Valve plate material :SS304, SS316, wear-resistant polymer material
Sealing material :EPDM, NBR, VITON
Medium: dust, feed, cement, a variety of powder, granular materials, etc
Drive mode: manual, turbine, pneumatic, electric
Please contact us if you need customized services. We will contact you with the price and availability in 24 hours.
| Product | Product Code | Purity | Size | Contact Us |
Powder butterfly valve has the characteristics of simple structure, butterfly plate wear resistance, long sealing life, simple installation and operation. The valve body is made of lightweight high pressure cast aluminum alloy, light weight, valve plate is a village with steel core wear-resistant polymer material, and cold resistant rubber sealing ring to form a high wear-resistant soft seal, wear resistance can also be applied, can be installed in the hopper, barrel, screw conveyor outlet and pneumatic transmission pipeline, flange surface can be selected according to the need to single flange surface or double flange, double flange butterfly valve
With 2 identical flange faces. The single flange valve has an outstretched connecting ring at the lower part for mounting the casing.
Powder butterfly valve has the characteristics of simple structure, butterfly plate wear resistance, long sealing life, simple installation and operation. The valve body is made of lightweight high pressure cast aluminum alloy, light weight, valve plate is a village with steel core wear-resistant polymer material, and cold resistant rubber sealing ring to form a high wear-resistant soft seal, wear resistance can also be applied, can be installed in the hopper, barrel, screw conveyor outlet and pneumatic transmission pipeline, flange surface can be selected according to the need to single flange surface or double flange, double flange butterfly valve
With 2 identical flange faces. The single flange valve has an outstretched connecting ring at the lower part for mounting the casing.
