Product Code : VF--DCC-D190-CU
Caliber :DN100~DN400
connection standard: PN10/16, ANSI150 DIN16, JIS10K, 16 k
Operating temperature :-15~85°C
Working pressure :PN0.1
Body material: carbon steel, cast aluminum alloy
Valve plate material :SS304, SS316, wear-resistant polymer material
Sealing material :EPDM, NBR, VITON
Medium: dust, feed, cement, a variety of powder, granular materials, etc. Drive mode: manual, turbine, pneumatic, electric
Please contact us if you need customized services. We will contact you with the price and availability in 24 hours.
| Product | Product Code | Purity | Size | Contact Us |
Powder butterfly valve has the characteristics of simple structure, butterfly plate wear resistance, long sealing life, simple installation and operation. The valve body is made of lightweight high pressure cast aluminum alloy, light weight, valve plate is lined with a steel core of wear resistant polymer material, and wear resistant rubber seal
It can be installed in the hopper, silo, mule rotary conveyor outlet and pneumatic conveying pipeline. The flange surface can be selected according to the needs of single flange surface or double flange surface. The double flange butterfly valve has two identical flange surfaces, and the lower part of the single flange valve is equipped with an extended connecting ring to install the casing
Powder butterfly valve has the characteristics of simple structure, butterfly plate wear resistance, long sealing life, simple installation and operation. The valve body is made of lightweight high pressure cast aluminum alloy, light weight, valve plate is lined with a steel core of wear resistant polymer material, and wear resistant rubber seal
It can be installed in the hopper, silo, mule rotary conveyor outlet and pneumatic conveying pipeline. The flange surface can be selected according to the needs of single flange surface or double flange surface. The double flange butterfly valve has two identical flange surfaces, and the lower part of the single flange valve is equipped with an extended connecting ring to install the casing
