Fluorine rubber butterfly valve, butterfly valve

Structural features of fluorine rubber butterfly valve:

1. The design is novel, reasonable, with a lightweight structure and quick opening and closing.

2. The operating torque is small, the operation is convenient and labor-saving.

3. It can be installed at any position and is easy to maintain.

4. The sealing parts can be replaced and the sealing performance is reliable, achieving zero leakage in both directions.

5. The sealing material has characteristics such as aging resistance, resistance to weak corrosion, and long service life.

Standard Specifications for Fluorine Rubber Butterfly Valve:

Design and manufacturing standard: gb/t 12238-2008

Structural length standard: GB/T 12221-2005

Connection flange standard: gb/t 9113

Pressure and temperature grade: GB/T 12224-2005

Test inspection standard: gb/t 13927-2008

The disc of the fluorine rubber butterfly valve is installed in the diameter direction of the pipeline. Within the cylindrical channel of the electrically coated rubber butterfly valve body, the disc-shaped butterfly plate rotates around the axis, with a rotation angle ranging from 0° to 90°. When the rotation reaches 90°, the butterfly valve is in the fully open state. The electrically coated rubber butterfly valve is generally installed horizontally in the pipeline. The product of the electrically coated rubber butterfly valve consists of a rubber-sealed butterfly valve and carbon steel or stainless steel valve plate and valve stem. The electrically coated rubber butterfly valve is suitable for temperatures of ≤ 80 - 120℃. It is controlled by an electric drive device and is widely used in pure pipelines such as food, beverages, medicine, chemical industry, etc., as well as industrial environmental protection, water treatment, high-rise buildings, and water supply and drainage pipelines for opening and closing or regulating the flow of media.

The disc of the fluorine rubber butterfly valve is installed in the diameter direction of the pipeline. In the cylindrical channel of the electrically lined rubber butterfly valve body, the disc-shaped butterfly plate rotates around the axis, with a rotation angle ranging from 0° to 90°. When the rotation reaches 90°, the butterfly valve is in the fully open state. The electrically lined rubber butterfly valve is generally installed horizontally in the pipeline. The product of the electrically lined rubber butterfly valve consists of a rubber-sealed butterfly valve and carbon steel or stainless steel valve plate and valve stem. The electrically lined rubber butterfly valve is suitable for a temperature of ≤ 80 - 120℃. It is controlled by an electric drive device and is widely used in pure pipelines such as food, beverages, medicine, chemical industry, etc., as well as industrial environmental protection, water treatment, high-rise buildings, and water supply and drainage pipelines for opening and closing or regulating the flow of media.

Packing of Standard Packing:

Typical bulk packaging includes palletized plastic 5 gallon/25 kg. pails, fiber and steel drums to 1 ton super sacks in full container (FCL) or truck load (T/L) quantities. Research and sample quantities and hygroscopic, oxidizing or other air sensitive materials may be packaged under argon or vacuum. Solutions are packaged in polypropylene, plastic or glass jars up to palletized 470 gallon liquid totes Special package is available on request. E FORUs’  is carefully handled to minimize damage during storage and transportation and to preserve the quality of our products in their original condition.
