Product Code : VCCF--D-D244-CU
Valve parameters:
Nominal pressure: 0.05MPa-0.1MPa;
Medium temperature: 600℃;
Nominal diameter: DN2000-DN4000;
Applicable medium: gas;
Connecting faran: ASME B16.5, ASME B16.47, HG 20623, HG20592, HG20615.
Leakage rate: 1%-3%.
Main materials:
Body: 16Mn, Q235, SS304, SS316, 2520, 310S;
Valve plate: 16Mn, Q235, SS304, SS316, 2520, 310S;
Valve shaft: 2Cr13, SS304, SS316, 2520, 310S.
Please contact us if you need customized services. We will contact you with the price and availability in 24 hours.
| Product | Product Code | Purity | Size | Contact Us |
Large diameter flange ventilation butterfly valve, diameter DN2000-DN4000, pressure PN0.1MPa, pneumatic, electric, worm gear operation. Model TD341W, TD941W, TD641W. Large diameter flanges ventilation butterfly valve is used for ventilation and dust removal, flue gas desulfurization and denitrification, gas purification, waste gas discharge, in power plants, chemical industry, metallurgy, building materials, electronics and other industries. Large diameter flange ventilation butterfly valve, suitable for pressure less than 0.1MPa, temperature less than 600℃ of all kinds of gas discharge and purification. Material: 16Mn, Q235, SS304, SS316, 2520, 310S
Large diameter flanges ventilation butterfly valve is used for ventilation and dust removal, flue gas desulfurization and denitrification, gas purification, waste gas discharge, in power plants, chemical industry, metallurgy, building materials, electronics and other industries.
Packing of Standard Packing:
Typical bulk packaging includes palletized plastic 5 gallon/25 kg. pails, fiber and steel drums to 1 ton super sacks in full container (FCL) or truck load (T/L) quantities. Research and sample quantities and hygroscopic, oxidizing or other air sensitive materials may be packaged under argon or vacuum. Solutions are packaged in polypropylene, plastic or glass jars up to palletized 470 gallon liquid totes Special package is available on request. E FORUs’ is carefully handled to minimize damage during storage and transportation and to preserve the quality of our products in their original condition
