Pneumatic dust butterfly valve, pneumatic cement special butterfly valve, VFS pneumatic material butterfly valvePneumatic dust butterfly valve, pneumatic cement special butterfly valve, VFS pneumatic material butterfly valve

V1FS/V2FS Pneumatic Dust Butterfly Valve - Product Overview:

The V1FS/V2FS pneumatic dust butterfly valve is composed of two semi-valves cast by gravity. The semi-valves are made of aluminum alloy, and the rotating valve plate is made of high molecular material, which has good sealing performance. The same circular flanges at the top and bottom have a top flange and a folded edge component, suitable for a flexible sleeve. The powder butterfly valve is mainly used for opening and closing material boxes, hoppers, and silos containing powdered or granular materials. It can be applied to the processing of all powdered and granular materials, and the valve uses the material's own gravity for diversion and pneumatic transmission of dry materials. The powder butterfly valve can be installed below the hopper, material box, silo, screw or other types of conveyors, as well as connected to pneumatic conveying pipelines. Due to the special structure of this valve and the use of engineering materials, it is always a very economical and highly efficient choice.

V1FS/V2FS Pneumatic Dust Butterfly Valve - Product Features:

1. Single flange valve, with top flange and flange edge component, suitable for connecting flexible tubing

2. Double flange valve, with the same flange at the top and bottom

3. Valve body is made by gravity casting, which is stronger than the pressure cast valve body

4. Rotating valve plate is made of high molecular material, resistant to wear

5. Few components, lightweight, easy to transport

V1FS/V2FS Pneumatic Dust Butterfly Valve - Main Parameters:

Valve model: FCD641X

Main material: Aluminum alloy, etc.

Size range: DN50 - DN500

Pressure range: 0.2 Mpa

Applicable temperature: Maximum 80.

The V1FS/V2FS pneumatic dust butterfly valve is composed of two semi-valves cast by gravity. The semi-valves are made of aluminum alloy, and the rotating valve plate is made of high molecular material, which has excellent sealing performance. The same circular flanges at the top and bottom have a top flange and a folded edge component, suitable for a flexible sleeve. The powder butterfly valve is mainly used for opening and closing material boxes, hoppers, and silos containing powdered or granular materials. It can be applied to the processing of all powdered and granular materials, and the valve uses the material's own gravity for diversion and pneumatic transmission of dry materials. The powder butterfly valve can be installed below the hopper, material box, silo, screw or other types of conveyors, as well as connected to pneumatic conveying pipelines. Due to the special structure of this valve and the use of engineering materials, it is always a very economical and highly efficient choice.
