Three eccentric butt-weld hard-sealed pneumatic butterfly valve, butt-weld hard-sealed pneumatic butterfly valve, pneumatic butterfly valve

 Product Features

1, clamp metal multi-level sealing butterfly valve clamp connection structure is simple, convenient installation and disassembly, light weight characteristics. Metal hard seal butterfly valve with three eccentric seal structure, valve seat and butterfly plate almost no wear, with more tight sealing function.

2, the sealing ring is made of stainless steel, with the double advantages of metal hard seal and elastic seal, no matter in the case of low temperature and high temperature, it has excellent sealing performance, corrosion resistance, long service life and other characteristics.

3. The sealing surface of the butterfly plate is hardfaced with cobalt-based carbide, and the sealing surface is wear-resistant and has long service life.4, the large size of the butterfly plate adopts quilting structure, high strength, large flow area, small flow resistance.

5, the metal hard seal butterfly valve has a two-way sealing function, the installation is not limited by the flow of the medium, nor by the influence of the space position, can be installed in any direction.

6, the driving device can be multi station (rotation 90° or 180°) installation, convenient for users to use.

Implementation standard

Design specification: GB/T 12238 API609

Structure length: GB/T 12221 API609 ASME B16.10

French connection: GB/T 9113 API609 ASME B16.5 ISO5752

Test and inspection: GB/T 13927 API598

Product Application

The three-seal flanged hard-sealed pneumatic butterfly valve adopts precise J-shaped elastic sealing rings and a three-seal multi-layer metal hard-sealing structure. It is widely used in industrial pipelines such as metallurgy, power, petrochemicals, water supply and drainage, and municipal construction where the medium temperature is ≤ 400℃, for regulating flow and interrupting fluid.

Packing of Standard Packing:

Typical bulk packaging includes palletized plastic 5 gallon/25 kg. pails, fiber and steel drums to 1 ton super sacks in full container (FCL) or truck load (T/L) quantities. Research and sample quantities and hygroscopic, oxidizing or other air sensitive materials may be packaged under argon or vacuum. Solutions are packaged in polypropylene, plastic or glass jars up to palletized 470 gallon liquid totes Special package is available on request. E FORUs’  is carefully handled to minimize damage during storage and transportation and to preserve the quality of our products in their original condition.
