Manual gas control valve, gas control valve, gate valve

Gas control valves are a type of gate valve and are mainly used in gases such as natural gas, petroleum gas, and natural gas.

The Z47WF gas control valve (leak-free gas plate gate valve) is specifically designed for natural gas, liquid petroleum gas, gas, and oil products. With its unique design, novel structure, and excellent sealing performance, it completely solves the problems of the valve not closing tightly or not opening due to gas coking, effectively improving the sealing performance and service life, and truly achieving zero leakage. Product features

The valve body is of casting structure.

The valve seat is sealed with an O-ring and a floating valve seat structure that applies pre-tightening force, ensuring bidirectional sealing of the valve inlet and outlet; moreover, the opening and closing torque of this structure is only half that of ordinary valves, enabling easy opening and closing of the valve. The valve seat is embedded with PTFE on the sealing surface, which provides dual sealing with PTFE against both metal and metal-to-metal. The PTFE sealing surface also has the function of removing dirt from the gate. The gate of the valve, whether fully open or fully closed, always fits the sealing surface, protecting the sealing surface from direct medium erosion, thereby extending the service life. When the valve is fully open, the channel is smooth as a straight line, with a very small flow resistance coefficient and no pressure loss, allowing for the passage of hairballs to clean the pipeline. When the valve is closed, the internal high pressure can be automatically relieved (see the working principle diagram), ensuring safe use. The closed-type valve body uses a sealed gear rotation opening and closing indication mechanism, which can clearly and permanently reflect the opening and closing status of the valve. The outer surface of the buried valve is treated with epoxy coal tar asphalt for corrosion protection, which can have the same lifespan as the pipeline.

enforce standards

Design Specifications: GB/T 12234

Structural Length: GB/T 12221

Connection Flange: JB/T 79.1

Testing and Inspection: JB/T 9092

Pressure-Temperature: GB/T 9131

Product Identification: GB/T 12220

Gas control valves are a type of gate valve and are mainly used in gases such as natural gas, petroleum gas, and natural gas.

The Z47WF gas control valve (leak-free gas plate gate valve) is specifically designed for natural gas, liquid petroleum gas, gas, and oil products. With its unique design, novel structure, and excellent sealing performance, it completely solves the problems of the valve not closing tightly or not opening due to gas coking, effectively improving the sealing performance and service life, and truly achieving zero leakage.
