Monel alloy gate valve, gate valve

Features and applications of Monel alloy gate valves:

1. Compact structure, well-designed, with good valve rigidity, smooth channel, and low flow coefficient.

2. Utilizing flexible graphite and fluorine-based packing, the sealing is reliable and the operation is light and flexible.

3. Drive methods include manual, electric, and gear-air transmission.

4. Structural forms: elastic wedge single gate plate, rigid wedge single gate plate, and double gate plate.

Technical specifications for Monel alloy gate valves:

Design standards: GB/T12234, API600, API6D

Structural length: GB/T12221, ASME B16.10

Connection flanges: HG, GB, JB, API, ANSI, ISO, BS, DIN

Test standards: JB/T9092, GB/T13927, API598

Main material of Monel alloy gate valves: M-30C, Monel400, Monelk500

Pressure rating: PN1.0 - 16.0 Mpa

Nominal diameter: DN15 - DN1000

Corresponding Monel alloy gate valve models:

Z11W-16M, Z11W-25M. Z11W-40M, Z11W-64M, Z11W-100M. Z11W-16M, Z11W-25M. Z11W-40M, Z11W64M, Z11W-100M, Z40W-16M, Z40W-25M, Z40W-40M, Z40W-64M, Z40W-100M, Z40W-16M, Z40W-25M. Z40W-40M, Z40W-64M, Z40W

Applicable medium: Highly corrosive medium.

Monel alloy gate valve: Compact structure, well-designed, with good valve rigidity, smooth channel, and low flow coefficient. It uses flexible graphite and fluorine-based packing, ensuring reliable sealing and easy, flexible operation. The driving methods include manual, electric, and gear-air transmission. Structural forms: elastic wedge type single gate plate, rigid wedge type single gate plate, and double gate plate forms.

The drawback of the structural form of the Monel alloy gate valve is that the circular gate plate moving laterally on the circular flow channel is only sensitive to the flow rate when it is at 50% of the valve's closed position. Moreover, when the gate plate is subjected to high-speed or high-density medium flow, it will cause severe vibration. If the valve seat is made into a V-shaped opening and is closely guided by the gate plate, it can also be used for throttling.

The Monel gate valve is a valve device made mainly of Monel alloy.The Monel gate valve is a valve device made mainly of Monel alloy. Through the synergistic effect of copper, iron, manganese and other elements in the nickel-based alloy, it has excellent corrosion resistance and sealing reliability. Through the synergistic effect of copper, iron, manganese and other elements in the nickel-based alloy, it has excellent corrosion resistance and sealing reliability. This valve controls the flow direction of the medium by opening and closing the pipeline, and also has the function of regulating the parameters of the transported medium. This valve realizes the control of medium flow direction by opening and closing the pipeline, and also has the function of regulating the parameters of the transported medium. Its structural design is compact and smooth, with a small flow resistance coefficient. Its structural design is compact and smooth, with a small flow resistance coefficient. It can be widely applied in pipeline systems for water, acids, solvents and natural gas, etc. It can be widely used in pipeline systems for water, acids, solvents and natural gas, etc. When closed, it can self-seal due to the medium pressure, and some models adopt a special design of forced sealing by external force. When closed, it can self-seal due to the medium pressure, and some models adopt a special design of forced sealing by external force.
