Product Code : VF--ZCC-Z168-CU
Nominal diameter DN50~DN800,
The working pressure was 1.0-1.6mpa
The nominal pressure PN10~16
Applicable temperature / ℃; ≤ 100 ℃
The valve body material is carbon steel (PZ673H-10C~16C), stainless steel (PZ673F-10P~16P PZ673Y-10P~16P), with slag discharge function of the gate valve.
PZ673H, PZ673F, PZ673Y pneumatic knife gate valve (knife gate valve) : pneumatic drive, clamp type connection, open rod parallel rigid single gate, the sealing surface of the valve seat is cemented carbide and polytetrafluorene,
Suitable medium; Pulp, sewage, coal slurry, ash slag cement mixture
Please contact us if you need customized services. We will contact you with the price and availability in 24 hours.
| Product | Product Code | Purity | Size | Contact Us |
Product Overview
PZ673H, PZ673F, PZ673Y pneumatic knife gate valve (knife gate valve) : Pneumatic drive, clamp connection, open rod parallel rigid single gate, the sealing surface of the valve seat is cemented carbide and PTFE, the nominal pressure PN10~16, the valve body material is carbon steel (PZ673H-10C~16C), stainless steel (PZ673F-10P~16P PZ673Y-10P~16P), Gate valve with slag discharge function.
How it works
PZ673H, PZ673F, PZ673Y pneumatic knife gate valve with solenoid valve, proximity switch and other accessories can complete the opening and closing two position action control and signal output, can also complete the automatic control of continuous action. Users can choose according to their actual needs. Nominal diameter DN50~DN800, working pressure 1.0~1.6MPa. The products are widely used in chemical industry, coal, sugar, sewage, papermaking and other fields, is an ideal sealing valve, especially suitable for papermaking industry in the pipeline for adjustment and throttling use.
Application
PZ673H, PZ673F, PZ673Y pneumatic knife gate valve with solenoid valve, proximity switch and other accessories can complete the opening and closing two position action control and signal output, can also complete the automatic control of continuous action. Users can choose according to their actual needs. Nominal diameter DN50~DN800, working pressure 1.0~1.6MPa. The products are widely used in chemical industry, coal, sugar, sewage, papermaking and other fields, is an ideal sealing valve, especially suitable for papermaking industry in the pipeline for adjustment and throttling use.
Packing of Standard Packing:
Typical bulk packaging includes palletized plastic 5 gallon/25 kg. pails, fiber and steel drums to 1 ton super sacks in full container (FCL) or truck load (T/L) quantities. Research and sample quantities and hygroscopic, oxidizing or other air sensitive materials may be packaged under argon or vacuum. Solutions are packaged in polypropylene, plastic or glass jars up to palletized 470 gallon liquid totes Special package is available on request. E FORUs’ is carefully handled to minimize damage during storage and transportation and to preserve the quality of our products in their original condition
