Jacketed insulation direct flow stop valve, jacketed insulation stop valve

Jacket insulation direct flow globe valve Product Overview:

The jacketed insulation straight-flow globe valve is based on the welding jacket between the two flanges of the Y-type globe valve. The side and bottom of the valve are arranged with two connecting ports of the insulation jacket, which are used to inject steam or other heat preservation and cold preservation media to ensure that the medium in the valve can work normally. It has good heat preservation and cold preservation characteristics, and can effectively reduce the heat loss of the medium in the pipeline. The insulation jacket globe valve adopts the integral jacket structure design, which can keep heat and cold evenly. The jacket is welded with carbon steel pipe, which is more resistant to pressure than cast. The jacket, outside of the body and the jacket are welded to allow a maximum pressure of 1MPa of steam or cold water.

Features of jacketed thermal insulation direct flow globe valve:

1, simple structure, unique design.

2, the sealing surface hardening treatment to resist wear.

3, the valve neck lining material has a low friction coefficient, greatly reduce torsion and axial wear, and eliminate surface abrasion.

4. The valve cavity device is composed of two parts, which is conducive to rapid disassembly and internal repair in place.

5. The structure of the tilt axis and the shape of the best flow channel, reduce the flow direction transformation and reduce the number of step-down.

6, the overall surface hardening of the seat: to provide reliable closure and long service life of the seat.

7, thread cover: prevent stuck and easy to assemble and disassemble.

8, valve shaft filling device: using the soft graphite of the ring infiltrated with carbon fiber cracks as filler, for the best leak-proof and durable.

9, reciprocating test 10000 times without fault, reliable performance to prevent external leakage.

Applications of jacketed insulated direct flow globe valves include:

Chemical, chemical fertilizer industry: suitable for chemical, chemical fertilizer industry pipeline, the steam into the jacket can prevent the crystallization of the medium.

Petroleum, chemical industry, metallurgy, pharmaceutical and other industries: widely used in petroleum, chemical industry, metallurgy, pharmaceutical and other kinds of systems, in order to transport high viscosity media will solidify at room temperature.

Heavy OIL TRANSMISSION PIPELINE: BECAUSE OF the use of steam jacket insulation, even if the outside temperature drops below zero, the valve is still flexible operation, is the ideal control valve for heavy oil transmission pipeline
