Integrated high-temperature titanium ball valve, titanium ball valve

Integrated high-temperature titanium ball valve: Also known as high-temperature titanium ball valve, it is made of integral titanium alloy, with an integrated forging without any leakage points. The sealing valve core and valve seat are coated with alloy steel for wear resistance and corrosion resistance at high temperatures. It is manually operated for opening and closing. It is a forged type with floating flange ball valve, with a narrowed neck. It has metal seals. The pressure rating is PN-16, and the diameter range is DN15-DN200. The integrated titanium ball valve has excellent stability and self-passivation properties in oxidizing films in harsh corrosive environments, which can resist various harsh working conditions and corrosive media. The stable oxide film on its surface has chemical stability in corrosive media. For neutral, oxidizing, and weak reducing medium environments, the inert oxide film itself has good stability. For high-temperature or low-pH reducing corrosive media, to improve the stability of the inert oxide film and surface hardness, methods such as adding corrosion inhibitors (such as air, water, heavy metal ions and anions), titanium surface ion modification treatment, and anodization treatment can be used to enhance the corrosion resistance and surface hardness of titanium in reducing media to meet usage requirements. It is used to cut off or connect the medium in the pipeline, and is widely used in chlor-alkali industry, soda ash industry, pharmaceutical industry, fertilizer industry, fine chemical industry, textile fiber synthesis and bleaching industry, basic organic acid and inorganic salt production, nitric acid industry, etc.

[Structural features and working principle] The ball and sealing ring in this type of valve adopt special processing techniques and sealing materials to ensure that the surface roughness and roundness of the ball are within the standard requirements, thereby improving the sealing performance and service life, and the ability to withstand high temperatures. The handwheel on the rotating plate drives the valve stem to rotate, allowing the medium to pass smoothly. The main feature of the high-temperature ball valve is its compact structure, reliable sealing, simple structure, convenient maintenance, with the sealing surface and the ball surface often in a closed state, which is not easily eroded by the medium, and is easy to operate and maintain. It is suitable for general working media such as water, solvents, acids and natural gas, and is also suitable for media with harsh working conditions such as oxygen, methane and ethylene, etc. It has been widely used in various industries. The valve body of the ball valve can be integral or combined.

The integrated high-temperature titanium ball valve is widely used in industries such as chlor-alkali, soda ash, pharmaceutical, fertilizer, fine chemical, textile fiber synthesis and bleaching, basic organic acid and inorganic salt production, nitric acid industry, etc.

Packing of Standard Packing:

Typical bulk packaging includes palletized plastic 5 gallon/25 kg. pails, fiber and steel drums to 1 ton super sacks in full container (FCL) or truck load (T/L) quantities. Research and sample quantities and hygroscopic, oxidizing or other air sensitive materials may be packaged under argon or vacuum. Solutions are packaged in polypropylene, plastic or glass jars up to palletized 470 gallon liquid totes Special package is available on request. E FORUs’  is carefully handled to minimize damage during storage and transportation and to preserve the quality of our products in their original condition
