Product Code : VF--QCC-Q347-CU
Valve parameters
Product model: Q641PFA-10C, Q641F46-16P, Q641F46-16R;
Nominal pressure: PN 0.6MPa - PN 1.6MPa; pound rating 150LB;
Nominal diameter: DN15 - DN250 (two-piece structure);
Connection method: Flange (American standard, Chinese standard, Japanese standard, German standard).
Material of the part
Valve body material: WCB carbon steel, CF8, CF8M, CF3M stainless steel;
Sphere material: Carbon steel, 304, 316, 316L stainless steel;
Valve stem material: 2Cr13, 304, 316;
Lining material: PFA, F46.
Please contact us if you need customized services. We will contact you with the price and availability in 24 hours.
| Product | Product Code | Purity | Size | Contact Us |
Structural features:
Pneumatic flange O-ring fluorine-coated ball valve
Structural features:
The fluid resistance is very low.The fluid resistance is very low. When the valve is fully open, the flow channel is smooth and unobstructed, and the fluid resistance is smaller than that of any other valve.
When the valve is fully open, the flow channel is smooth and unobstructed, and the fluid resistance is smaller than that of any other valve.
2.2. The switch operates quickly and conveniently. The switch operates quickly and conveniently. All you need to do is rotate the ball body by 90 degrees to complete the opening or closing action.
3. All you need to do is rotate the ball body by 90 degrees to complete the opening or closing action.
3. The molding process is adopted to embed the lining material into the inner wall of the valve body. The molding process is adopted to embed the lining material into the inner wall of the valve body. The ball core is fully lined, and it can resist the corrosion of strong acids and strong bases.
4. The ball core is fully lined, and it can resist the corrosion of strong acids and strong bases.
4. The sphere is integrated with the valve stem, eliminating the rotational angle difference. The sphere is integrated with the valve stem, eliminating the rotational angle difference. It will not cause the valve stem to be pushed out due to pressure changes, ensuring the reliability of use.
The pneumatic fluoroplastic O-type ball valve is a rotary type cut-off ball valve. It consists of a cylinder piston type actuator and a fluoroplastic lined ball valve. Due to the fact that the inner cavity of the valve body and the ball are fully lined with fluoroplastic, it has reliable corrosion resistance and sealing performance. It can be widely applied in industrial sectors such as chemical, petroleum, metallurgy, medicine, and power, to achieve the cutting or regulation of strong corrosive media like acids and alkalis during production processes.
