Product Code : VF--DCC-D183-CU
Nominal diameter; DN40 ~ 500mm
Nominal pressure; PN1.0, 1.6MPa
Valve shaft material; Carbon steel, 304/316/316L stainless steel
Valve body material; Ductile iron, carbon steel, stainless steel
Valve plate material; Ductile iron, 304/316/316L stainless steel, nylon
Valve seat seal; EPDM, NBR, wear-resistant rubber
Structural form; Center line type, no pin type
Temperature; EPDM≤80℃; NBR≤68℃
Applicable medium; Water, air, natural gas, gas
Feature; Wide use, low overall cost, large flow, small flow resistance
Widely used in food, environmental protection, light industry, petroleum, paper, chemical industry, teaching and research equipment, electric power and other industries of industrial automatic control system.
Please contact us if you need customized services. We will contact you with the price and availability in 24 hours.
| Product | Product Code | Purity | Size | Contact Us |
Feature; Wide use, low overall cost, large flow, small flow resistance
Widely used in food, environmental protection, light industry, petroleum, paper, chemical industry, teaching and research equipment, electric power and other industries of industrial automatic control system.
Application;
D941X reliable performance, simple matching, large flow capacity, especially suitable for the medium is thick, containing particles, fiber nature of the occasion. At present, the valve is widely used in food, environmental protection, light industry, petroleum, papermaking, chemical industry, teaching and research equipment, electric power and other industries of industrial automatic control system.
Packing of Standard Packing:
Typical bulk packaging includes palletized plastic 5 gallon/25 kg. pails, fiber and steel drums to 1 ton super sacks in full container (FCL) or truck load (T/L) quantities. Research and sample quantities and hygroscopic, oxidizing or other air sensitive materials may be packaged under argon or vacuum. Solutions are packaged in polypropylene, plastic or glass jars up to palletized 470 gallon liquid totes Special package is available on request. E FORUs’ is carefully handled to minimize damage during storage and transportation and to preserve the quality of our products in their original condition.
