Product Code : VCCF--D-D250-CU
Valve parameters:
Nominal pressure: 0.05MPa-0.1MPa;
Medium temperature: 1000℃;
Nominal diameter: DN50-DN3000;
Applicable medium: flue gas, dust gas, hot and cold air, waste gas;
Connection: flange type;
Connection size: ASME B16.5, ASME B16.47, HG 20623, HG20592, HG20615;
Leakage rate: 1%-3%.
Main materials:
Body: 16Mn, Q235, SS304, SS316, 2520, 310S;
Valve plate: 16Mn, Q235, SS304, SS316, 2520, 310S;
Valve shaft: 2Cr13, SS304, SS316, 2520, 310S;
Operation: Worm gear.
Please contact us if you need customized services. We will contact you with the price and availability in 24 hours.
| Product | Product Code | Purity | Size | Contact Us |
Worm flange ventilation butterfly valve operated by worm wheel, model TD341W, diameter DN50-DN3000, pressure PN0.1MPa. Valve material: Q235, 304, 316, 316L, 2520, 310S stainless steel.
The worm flanged ventilation butterfly valve is closed to allow small leakage, is a non-closed butterfly valve, designed for the need of ventilation conditions and butterfly valve, applicable temperature less than 1000℃, medium: boiler smoke, dust gas, hot and cold air, exhaust gas and so on. In chemical, building materials, power plants, metallurgy, glass, electronics and other industries have the need for ventilation butterfly valve place.
When installing the worm flanged ventilation butterfly valve, attention should be paid to the flow direction of the medium, so that the opening direction of the butterfly plate is consistent with the flow direction of the pipeline medium, which is conducive to the self-cleaning effect of the medium flow rate. With the design of the pipeline, the installation position has different positions such as horizontal, vertical and bending.
The worm flanged ventilation butterfly valve is closed to allow small leakage, is a non-closed butterfly valve, designed for the need of ventilation conditions and butterfly valve, applicable temperature less than 1000℃, medium: boiler smoke, dust gas, hot and cold air, exhaust gas and so on. In chemical, building materials, power plants, metallurgy, glass, electronics and other industries have the need for ventilation butterfly valve place.
