Product Code : VF--ZCC-Z182-CU
BZ41H, BZ41W, BZ41Y type insulation sleeve type gate valve;
Nominal pressure; PN16~PN40
Mode of operation; Manual,
Connection mode; Flange connection,
Valve; Open wedge type rigid single ram,
Reading seat sealing cover material; Alloys and stainless steel,
Nominal pressure; Pn16-pn40,
Working temperature ℃; 200 or less
Suitable medium; Acids and bases
Valve body; Carbon steel (BZ41H-16C~BZ41H-40 BZ41Y-16C~BZ41Y-40), chromium nickel-titanium stainless steel (BZ41W-16P~BZ41W-40P BZ41Y-16P~BZ41Y-40P), chromium nickel-clamp titanium stainless steel (BZ41W-16R-BZ41W-40R BZ41Y-16R-BZ41Y-40R), a gate valve with thermal insulation function. It is mainly used in various systems such as petroleum, chemical industry, metallurgy, pharmacy, etc. It can keep heat and prevent medium crystallization to transport high viscosity medium that will solidify under normal temperature.
Design and manufacture: GB12234
Flange size: JB/T79GB9113
Pressure temperature: GB9131
Structure length: GB12221
Butt welding connection size: -
Inspection and test: GB13927
Please contact us if you need customized services. We will contact you with the price and availability in 24 hours.
| Product | Product Code | Purity | Size | Contact Us |
Stainless steel insulated gate valves - Overview
BZ41H/W/Y stainless steel insulation gate valve is mainly used in petroleum, chemical industry, metallurgy, pharmaceutical and other kinds of systems, the valve jacket welding between the two flanges, the side of the valve, the bottom is provided with a jacket connection port, jacket can flow freely through steam or other hot insulation medium, to ensure that the viscous medium can flow smoothly through the valve.
Ii. -- Standards
1. Design and manufacture according to GB12234-89
2, structure length according to GB12221-89
3, flange size according to JB/T79-94
4, valve inspection and test according to GB13927
BZ41H/W/Y stainless steel insulation gate valve is mainly used in petroleum, chemical industry, metallurgy, pharmaceutical and other kinds of systems, the valve jacket welding between the two flanges, the side of the valve, the bottom is provided with a jacket connection port, jacket can flow freely through steam or other hot insulation medium, to ensure that the viscous medium can flow smoothly through the valve.
