Product Code : VF--ZCC-Z170-CU
Diameter range: DN50~DN800,
Nominal pressure PN10~16,
Applicable temperature / ℃; ≤ 100
Applicable medium; Pulp, sewage, coal slurry, ash-slag cement mixture
The valve body material is carbon steel (PZ73H-10C/16C), stainless steel (PZ73F-10P/16P PZ73Y-10P/16P), with slag discharge function of the gate valve
Widely used in paper making, pulp industry, industrial sewage and municipal sewage treatment, chemical plants, fly ash treatment, bulk material transportation, food and beverage industry requirements and working conditions slow down the environmental conditions.
Please contact us if you need customized services. We will contact you with the price and availability in 24 hours.
| Product | Product Code | Purity | Size | Contact Us |
Product Overview
PZ73H, PZ73F, PZ73Y manual knife gate valve: Manual drive, clamp connection, clear rod parallel rigid single gate, valve seat sealing surface for carbide and polytetrafluorethylene, nominal pressure PN10~16, valve body material for carbon steel (PZ73H-10C/16C), stainless steel (PZ73F-10P/16P PZ73Y-10P/16P), with slag discharge function of the gate valve.
Principle of structure
The circular channel design is adopted, the upper end of the knife plate is installed with teflon, mud scraper, wear-resistant folding cone made of poly resin or Ni wear-resistant cast iron is installed at the inlet end of the knife gate valve, and multiple flushing ports can be set around the valve body. The bottom end of the cutter board is processed into a blade, with high finish and good sealing. Widely meet the requirements of paper making, pulp industry, industrial sewage and municipal sewage treatment, chemical plants, fly ash treatment, bulk material transportation, food and beverage industry use requirements and working conditions slow down the environmental conditions.
Product Use
Widely used in paper making, pulp industry, industrial sewage and municipal sewage treatment, chemical plants, fly ash treatment, bulk material transportation, food and beverage industry requirements and working conditions slow down the environmental conditions.
Packing of Standard Packing:
Typical bulk packaging includes palletized plastic 5 gallon/25 kg. pails, fiber and steel drums to 1 ton super sacks in full container (FCL) or truck load (T/L) quantities. Research and sample quantities and hygroscopic, oxidizing or other air sensitive materials may be packaged under argon or vacuum. Solutions are packaged in polypropylene, plastic or glass jars up to palletized 470 gallon liquid totes Special package is available on request. E FORUs’ is carefully handled to minimize damage during storage and transportation and to preserve the quality of our products in their original condition
