Product Code : VF--ZCC-Z169-CU
Diameter range: DN50~DN800,
Applicable temperature / ℃ : ≤ 100℃,
Nominal pressure PN10~16,
The valve body material is carbon steel (PZ973H-10C~16C), stainless steel (PZ973F-10P~16P PZ973Y-10P~16P), with slag discharge function of the gate valve.
Suitable medium; Pulp, sewage, coal slurry, ash slag cement mixture
Used in sewage, papermaking, chemical industry, coal, sugar and other fields, especially suitable for papermaking industry in the pipeline for adjustment and throttling use.
PZ973F, PZ973Y, PZ973H electric knife gate valve (knife gate valve) : electric drive, sandwich connection, bright rod parallel rigid single gate, the sealing surface of the valve seat is cemented carbide and PTFE
Please contact us if you need customized services. We will contact you with the price and availability in 24 hours.
| Product | Product Code | Purity | Size | Contact Us |
Product Overview
PZ973F, PZ973Y, PZ973H electric knife gate valve (knife gate valve) : Electric drive, clamp connection, open rod parallel rigid single gate, the sealing surface of the valve seat is cemented carbide and PTFE, nominal pressure PN10~16, the valve body material is carbon steel (PZ973H-10C~16C), stainless steel (PZ973F-10P~16P PZ973Y-10P~16P), Gate valve with slag discharge function
Product structure
Ultra-short structure length, save material, can greatly reduce the overall weight of the pipeline system. The effective space occupied is small, can effectively support the strength of the pipeline, can reduce the possibility of pipeline vibration. Austenitic stainless steel is selected for the gate, which can greatly improve the corrosion resistance and effectively prevent the sealing leakage caused by the gate corrosion. Equipped with multi-rotary electric device, make the valve plate up and down linear movement, realize remote control valve opening or closing. Diameter range: DN50~DN800, use temperature: ≤ 100℃, used in sewage, papermaking, chemical, coal, sugar and other fields, especially suitable for papermaking industry in the pipeline for regulating and throttling use.
Product Use
PZ973F, PZ973Y, PZ973H electric knife gate valve (knife gate valve) : Electric drive, clamp connection, open rod parallel rigid single gate, the sealing surface of the valve seat is cemented carbide and PTFE, nominal pressure PN10~16, the valve body material is carbon steel (PZ973H-10C~16C), stainless steel (PZ973F-10P~16P PZ973Y-10P~16P), Gate valve with slag discharge function, used in sewage, papermaking, chemical, coal, sugar and other fields, especially suitable for papermaking industry in the pipeline for regulation and throttling use.
