Product Code : VF--ZHCC-ZH65-CU
Nominal diameter (mm): 25 - 400
Nominal pressure (MPa): 0.6 - 1.6 - 4.0 - 6.4
Stroke (mm): 16 - 25 - 40 - 60 - 100
Flow characteristic: Linear, Equal Percentage, Quick Opening Type
Medium temperature (℃): -40 - 230℃ (Normal Temperature Type), Finned type 230 - 450℃ (Medium Temperature Type), Special order -100 - 600℃
Flange standard: Complies with JB78-59, JB79-59 standards. Can be ordered and produced according to JB/79.1-94, JB/79.2-94, ANSI, JIS, DIN, etc.
Valve body material: PN (MPa): 0.6, 1.6; WCB (ZG230-450); CF3, CF8, CF8M (4.0, 6.4); WCB (ZG230-450), ZG1Cr18Ni9Ti, ZG0Cr18Ni12Mo2Ti (CF8, CF8M)
Valve body type: Straight-through single-seat cast ball valve
Valve core material: 1Cr18Ni9, 0Cr18Ni12Mo2Ti (CF8, CF8M)
Upper valve cover form: Ordinary type (Normal Temperature Type), Heat plate type (Medium Temperature Type), Low temperature type
Ratio of adjustable opening R: 50:1
Air source connector; M16×1.5
Please contact us if you need customized services. We will contact you with the price and availability in 24 hours.
| Product | Product Code | Purity | Size | Contact Us |
I. ZJHM Pneumatic Sleeve Control Valve - Overview
The ZJHM type pneumatic sleeve regulating valve is small in size, lightweight, high in performance and large in capacity. It is a new generation of universal regulating valve product that complies with IEC standards. It is suitable for general fluid media and production process systems under various process conditions. This product is composed of a new type of pneumatic multi-spring diaphragm actuator and a low-flow resistance sleeve valve.
II. ZJHM Pneumatic Sleeve Control Valve - Features
By using a balanced core, the unbalanced force is small, allowing for a large pressure difference and ensuring stable operation.
2. The valve core has a large guiding surface, which can alleviate the oscillations caused by eddy currents and impacts, and reduce damage.
3. The noise level is reduced by approximately 10 bd compared to ordinary single or double-seat regulating valves.
4. Simple structure, easy to assemble, disassemble and maintain.
The ZJHM type pneumatic sleeve regulating valve is small in size, lightweight, high in performance and large in capacity. It is a new generation of universal regulating valve product that complies with IEC standards. It is suitable for general fluid media and production process systems under various process conditions. This product is composed of a new type of pneumatic multi-spring diaphragm actuator and a low-flow resistance sleeve valve.
