Product Code : VF--ZHCC-ZH46-CU
Valve body: ZG230-450, ZGCr18Ni12MoTi, ZG1Cr18Ni9Ti
Valve seat: 1Cr18Ni9Ti, Cr18Ni12Mo2Ti
Valve core: 1Cr18Ni9Ti, Cr18Ni12Mo2Ti
Bellows sleeve: 1Cr18Ni9Ti, Cr18Ni12Mo2Ti
Balancing bellows: 1Cr18Ni9Ti
Heat shield: H62, 1Cr18Ni9Ti
Capillary tube: H62, 1Cr18Ni9Ti Connection: 35, 1Cr18Ni9Ti
Nominal diameter D (mm) 15 - 20
Nominal pressure PN (MPa); 1.6, 4.0
Please contact us if you need customized services. We will contact you with the price and availability in 24 hours.
| Product | Product Code | Purity | Size | Contact Us |
The V230W type self-operated temperature regulating valve is mainly composed of a control valve and a temperature controller. It is an energy-saving product that can automatically adjust without the need for external energy sources, relying on the temperature changes of the controlled medium itself. It is mainly applicable for the automatic temperature control in various heat exchangers of non-corrosive gases, steam, hot water, oil and other media. It is widely used in urban heating, heating systems, as well as in industrial sectors such as petrochemicals, printing and dyeing, pharmaceuticals, and boilers.
This series of products have a nominal pressure of PN16 or PN40, and a nominal diameter ranging from 15 to 200 mm. The temperature adjustment range is from 0 to 270℃.
The V230W type self-operated temperature regulating valve is mainly composed of a control valve and a temperature controller. It is an energy-saving product that can automatically adjust without the need for external energy sources, relying on the temperature changes of the controlled medium itself. It is mainly applicable for the automatic temperature control in various heat exchangers of non-corrosive gases, steam, hot water, oil and other media. It is widely used in urban heating, heating systems, as well as in industrial sectors such as petrochemicals, printing and dyeing, pharmaceuticals, and boilers.
