The working principle of the ZJHP pneumatic single-seat regulating valve

The main working principle of the ZJHP pneumatic single-seat regulating valve is to use control signals (such as air pressure, electrical signals, etc.) to drive the actuator, thereby pushing the valve stem and valve core to move within the valve body. When the valve core moves, it will change the flow area between the valve core and the valve seat, thereby regulating parameters such as the flow rate and pressure of the fluid.

Specifically, when the control signal sends a positive signal to the actuator, the actuator will push the valve stem and valve core upward, reducing the flow area between the valve core and the valve seat, thereby increasing the pressure and flow rate of the fluid. Conversely, when the control signal sends a negative signal to the actuator, the actuator will push the valve stem and valve core downward, increasing the flow area between the valve core and the valve seat, thereby reducing the pressure and flow rate of the fluid.

Specification standards for ZJHP pneumatic single-seat regulating valve

The ZJHP pneumatic single-seat regulating valve complies with relevant domestic and international standards. The details are as follows:

1. API 600 standard: The valve body and valve cover of ZJHP pneumatic single-seat regulating valve are designed, manufactured and inspected in accordance with API 600 standards. Its structure complies with the requirements of API 600 standards and has sufficient strength and rigidity to withstand the pressure and temperature of the pipeline system.

2. ASME B16.34 standard: The flange connection dimensions and bolt loads of ZJHP pneumatic single-seat regulating valve are designed, manufactured and inspected in accordance with ASME B16.34 standards. Its flange connection dimensions comply with the requirements of ASME B16.34 standards and can be reliably connected to various pipeline systems.

3. ANSI 125 grade: The sealing material of ZJHP pneumatic single-seat regulating valve adopts ANSI 125 grade materials, which have excellent sealing performance and service life.

4. CE standard: ZJHP pneumatic single-seat regulating valve is manufactured and inspected in accordance with the CE standard, meeting the safety requirements of the European market for pressure equipment.

The ZJHP pneumatic single-seat regulating valve is an efficient and high-performance regulating valve, widely used in pipeline systems of industries such as petroleum, chemical engineering, and power. It is employed to control various parameters of fluids (such as gases, liquids, slurries, etc.) including flow rate, pressure, and temperature. This regulating valve features a simple structure, easy maintenance, and high reliability. It possesses excellent regulating performance and a long service life, and is an indispensable key component in modern industrial control systems.
