Product Code : VF--ZHCC-ZH36-CU
Valve body type: Straight-through type
Valve cover form: Standard type
Heat dissipation type
Flow characteristics: Quick opening
Bore range: DN15 - 300 (1/2" - 12")
Pressure rating: PN1.6, 4.0 Mpa (ANSI 150, 300LB)
Leakage grade: ASME B16.104 V (soft seal)
ASME B16.104 IV (hard seal)
Pipe connection method: Flanged
Set value deviation: ±8%
Applicable temperature range: -30° ～ 350°
Actuating mechanism type: Diaphragm actuating mechanism (self-contained)
Piston actuating mechanism (self-contained)
Please contact us if you need customized services. We will contact you with the price and availability in 24 hours.
| Product | Product Code | Purity | Size | Contact Us |
The 30D01 self-operated (after valve) pressure control valve consists of a control valve, an actuator and a spring with a set pressure. It is suitable for non-corrosive liquids, gases and steam. It functions as a pressure control valve after the system pipeline, and the control valve closes when the pressure after the valve rises.
Control Valve Parameter Description:
Characteristics of the valve internals:
1. Built-in bellows with a pressure balancing structure, featuring high sensitivity.
2. Compact structure, reliable performance, and maintenance-free.
3. Adopting standard modular design.
4. Through combinations, multiple control functions can be achieved.
Valve body type: Straight-through type
Valve cover form: Standard type
Heat dissipation type
The 30D01 self-operated (after valve) pressure control valve consists of a control valve, an actuator and a spring with a set pressure.The 30D01 self-operated (after valve) pressure control valve is composed of a control valve, an actuator and a spring with a set pressure. It is suitable for non-corrosive liquids, gases and vapors. It is suitable for non-corrosive liquids, gases and steam. It plays the role of pressure control after the valve in the system pipeline. It functions as a pressure control valve after the system pipeline, and the control valve closes when the pressure after the valve rises. When the pressure after the valve rises, the control valve closes.
