Product Code : VF--ZHCC-ZH62-CU
Nominal pressure is PN16, 40, 64;
Nominal diameter range is DN25 - 300.
Applicable fluid temperature ranges from -60℃ to +450℃.
Leakage standard is level IV. Flow characteristics are linear and parabolic.
Flow characteristic Linear
Medium temperature ℃ -20 - 200, -40 - +250 (normal temperature type), -40 - 315 (medium temperature type)
Flange size Flange size for cast iron is according to JB79-59, flange size for cast steel is according to JB79-59
Flange type Flange sealing surface type is according to JB77-59, among which cast steel flange is smooth type, cast steel flange is concave type
Valve body material HT200, ZG230-450, ZG1Cr18Ni9
Valve core material 1Cr18Ni9
Upper valve cover type Ordinary type (normal temperature type), heat plate type (medium temperature type)
Ratio of adjustment 30:1
Air source connection M16×1.5
Please contact us if you need customized services. We will contact you with the price and availability in 24 hours.
| Product | Product Code | Purity | Size | Contact Us |
The ZJHQ/ZJHX pneumatic diaphragm three-way regulating valve adopts a cylindrical thin-walled window-shaped valve core guide, which is different from the sleeve guide of the piston-shaped valve core. It is equipped with a multi-spring actuator and has the advantages of simple structure, light weight, small size, and convenient disassembly and assembly. It is widely used in processes for precisely controlling gases, liquids, etc., such as maintaining pressure, flow rate, temperature, and liquid level at given values. It is suitable for situations where one fluid is divided into two streams through a three-way valve or where two fluids are combined into one fluid through a three-way valve.
This series of products come in two types: three-way confluence and three-way diversion. The nominal pressure ranges from PN16 to PN64; the nominal diameter ranges from DN25 to DN300. The applicable fluid temperature ranges from -60℃ to +450℃. The leakage standard is level IV. The flow characteristics include linear and parabolic types.
The ZJHQ/ZJHX pneumatic diaphragm three-way regulating valve adopts a cylindrical thin-walled window-shaped valve core guide, which is different from the sleeve guide of the piston-shaped valve core. It is equipped with a multi-spring actuator and has the advantages of simple structure, light weight, small size, and convenient disassembly and assembly. It is widely used in processes for precisely controlling gases, liquids, etc., such as maintaining pressure, flow rate, temperature, and liquid level at given values. It is suitable for situations where one fluid is divided into two streams through a three-way valve or where two fluids are combined through a three-way valve into one fluid.
