Product Code : VF--ZHCC-ZH59-CU
Nominal diameter (mm) 20 - 20
Nominal Pressure (MPa): 1.6, 4.0, 6.4
Natural Flow Characteristics: Quick Opening
Operating Temperature °C: Liquid ≤ 140; Gas ≤ 80; With condenser and heat sink ≤ 350
Suitable Media: Gas, Steam, Low-viscosity Liquids
Flange Dimensions and Types: PN10, 16, 40, GB9113-88, PN64, JB/T7-94; PN10, 16 convex type, PN40, 64 concave type
Or other standard types of flanges can be selected according to user requirements (such as: ANSI, JIS, DIN, etc. standards)
Structural Length: According to GB12221-89 standard
Optional Accessories: Condenser (for occasions where the medium is steam), heat sink, etc.
Actuator Signal Interface: Internal thread M16×1.5
Please contact us if you need customized services. We will contact you with the price and availability in 24 hours.
| Product | Product Code | Purity | Size | Contact Us |
ZZYP Self-Actuating Pressure Regulator - Overview
The ZZYP self-operated pressure regulating valve is a type of pressure regulating device that does not require external energy. It uses the energy of the controlled medium itself as the power source, introducing it into the actuating chamber to generate thrust, thereby controlling the movement of the throttling element to achieve automatic regulation. It has comprehensive functions of measurement, execution, and control. It can be widely used in various equipment in the self-control systems of the petroleum, chemical, power station, light industry, and printing and dyeing industries in places without air or electricity. It is used for reducing pressure, stabilizing pressure (for regulating the pressure after the valve), pressure relief, and stabilizing pressure (for regulating the pressure before the valve) of various gas, liquid, and steam media. According to different working conditions of users, different valve core structure types and different actuators can be selected to achieve the best control effect.
The ZZYP self-operated pressure regulating valve is a type of pressure regulating device that does not require external energy. It uses the energy of the controlled medium itself as the power source, introducing it into the actuating chamber to generate thrust, thereby controlling the movement of the throttling element to achieve automatic regulation. It has comprehensive functions of measurement, execution, and control. It can be widely used in various equipment in the self-control systems of the petroleum, chemical, power station, light industry, and printing and dyeing industries in places without air or electricity. It is used for reducing pressure, stabilizing pressure (for regulating the pressure after the valve), pressure relief, and stabilizing pressure (for regulating the pressure before the valve) of various gas, liquid, and steam media. According to different working conditions of users, different valve core structure types and different actuators can be selected to achieve the best control effect.
