Product Code : VF--ZHCC-ZH61-CU
Form: Straight casting ball valve
Nominal diameter: 25 - 200mm
Nominal pressure: 1.6, 4.0, 6.4 MPa
Flange standard: JB/T79.1, 79.2-94, etc.
Upper valve cover: Standard type - 17~+230℃, Heat dissipation type +230~+450℃, Low temperature type -60~-196℃, Bellows sealed type -40~+350℃
Press fitting type: Bolt compression type
Material: Cast steel (ZG230-450), Cast stainless steel (ZG1Cr18Ni9Ti, ZG0Cr18Ni12Mo2Ti), etc.
Sealing packing: V-shaped polytetrafluoroethylene packing, In-situ polytetrafluoroethylene asbestos packing, Asbestos textile packing, Graphite packing
III. Electronic Electric Single-seat Control Valve - Valve Internal Components:
Valve Core Type: Single-seat Piston Type Valve Core
Flow Characteristics: Equal Percentage and Linear Characteristics Materials: Stainless steel (1Cr18Ni9Ti, 1Cr18Ni12Mo2Ti, 17-4PH, 9Cr18, 316L), stainless steel overlay with Samteley alloy, titanium and corrosion-resistant alloys, etc.
Please contact us if you need customized services. We will contact you with the price and availability in 24 hours.
| Product | Product Code | Purity | Size | Contact Us |
The ZDLP electronic electric single-seat control valve is composed of the 3810L type (or PSL series) linear electric sub-motor actuator and a straight-through single-seat valve. It incorporates servo functionality and accepts unified 4-20mA or 1-5V·DC standard signals. These signals are converted into corresponding linear displacements, automatically controlling the opening degree of the control valve to achieve continuous regulation of process parameters such as pressure, flow, temperature, and liquid level in the pipeline.
Single-seat valves are suitable for applications where leakage is strictly controlled, where the pressure difference before and after the valve is low, and where the medium has a certain viscosity and contains a small amount of fibers. They are widely used in industries such as power, metallurgy, chemical engineering, petroleum, environmental protection, light industry, and equipment.
Single-seat valves are suitable for applications where leakage is strictly controlled, where the pressure difference before and after the valve is low, and where the medium has a certain viscosity and contains a small amount of fibers. They are widely used in industries such as power, metallurgy, chemical engineering, petroleum, environmental protection, light industry, and equipment.
