Product Code : VF--ZHCC-ZH60-CU
Nominal diameter (mm) 20 - 40
Nominal Pressure (MPa); 0.6 1.6 4.0 6.4
Flow Characteristics; Linear, Equal Percentage, Quick Opening Type
Medium Temperature (℃); -15 to 200 (Normal Temperature Type), -40 to +250, -40 to +450 (Medium Temperature Type), -100 to +200 (Low Temperature Type)
Flange Dimensions; Cast Iron Flange Dimensions in accordance with JB78, Cast Steel Flange Dimensions in accordance with JB79
Flange Form; Compliant with JB78-59, JB79-59 standards, can be ordered and produced according to JB/79.1-94, JB/79.2-94, ANSI, JIS, DIN, etc. standards
Valve Body Material; WCB(ZG230-450) CF3CF8 CF8M
Valve type: Straight single-seat cast ball valve
Valve core material: 1Cr18Ni9, 0Cr18Ni12Mo2Ti, CF8, CF8M
Upper valve cover type: Ordinary type (normal temperature type), heat plate type (medium temperature type), low-temperature type
Optional accessories: Positioner, handwheel, electric/air converter, air filter and pressure reducer
Ratio of adjustable range R: 30:1
Air source connector: M16×1.5
Please contact us if you need customized services. We will contact you with the price and availability in 24 hours.
| Product | Product Code | Purity | Size | Contact Us |
Pneumatic Diaphragm Single-Seat Control Valve - Overview
The ZMAP/ZMBP pneumatic diaphragm single-seat control valve is the most commonly used actuator in automatic control systems. It consists of a pneumatic diaphragm actuator and a low-flow resistance regulating valve. The single-seat is suitable for applications where leakage is strictly controlled, where the pressure difference before and after the valve is low, and where there is certain viscosity and fibers in the medium; the double-seat valve has the characteristics of small unbalanced force, large allowable pressure difference, and large flow capacity, and is suitable for applications where leakage requirements are not strict; the sleeve valve has good stability, is less prone to vibration, has low noise, and is less sensitive to temperature, and is suitable for applications with large pressure differences and where leakage requirements are not strict.
