Product Code : VF--DCCC-DC67-CU
Product Specifications:
Product Specifications: DN3 - DN500
Applicable Media: Air, water, oil, corrosive fluids, etc.
Control Mode: Normally Closed, Normally Open, Self-Preserving
Valve Body Material: Cast steel, brass, aluminum, stainless steel (cast steel cannot be used for corrosive fluids)
Power Supply Voltage: DC12 - 220V AC24 - 380V
Media Temperature: -50 ~ (0, +120)℃
Connection Method: Flange, Welding, Internal Thread (External Thread and special interfaces can be customized or equipped with adapters)
Media Viscosity: Less than 50 Cst (greater than this requires customization)
Protection Performance: Dustproof, Waterproof, Explosion-proof. Choose according to working conditions
Connection Method: Terminal Block Type; Lead-in Type; Plug Type
Leakage: Zero
Please contact us if you need customized services. We will contact you with the price and availability in 24 hours.
| Product | Product Code | Purity | Size | Contact Us |
Structural features:
Adapted to the characteristics of each series of solenoid valves;
When the solenoid valve coil is de-energized or burned out, the handle can be used to open or close the solenoid valve;
Easy to operate and stable in performance;
Stainless steel piston structure, good sealing performance;
Special coil, less prone to burning out.
Working principle:
Applicable to the working principle of each series of solenoid valves.
Signal feedback:
When the valve is open, the signal common line and the open signal line are connected;
When the valve is closed, the signal common line and the close signal line are connected.
Note: Electromagnetic valves with manual function have the same size as ordinary electromagnetic valves.
Product application:
It is widely used in military industry, aerospace, shipbuilding industry, nuclear industry, petrochemical industry, power industry, chemical industry, light industry, machinery industry, scientific research, drying equipment, boilers, water supply and drainage, fire protection, food and medical equipment, cleaning equipment, etc. in the automatic control systems of pipeline media.
Packing of Standard Packing:
Typical bulk packaging includes palletized plastic 5 gallon/25 kg. pails, fiber and steel drums to 1 ton super sacks in full container (FCL) or truck load (T/L) quantities. Research and sample quantities and hygroscopic, oxidizing or other air sensitive materials may be packaged under argon or vacuum. Solutions are packaged in polypropylene, plastic or glass jars up to palletized 470 gallon liquid totes Special package is available on request. E FORUs’ is carefully handled to minimize damage during storage and transportation and to preserve the quality of our products in their original condition.
