Threaded explosion-proof solenoid valve, explosion-proof solenoid valve, solenoid valve

The main working principle of the threaded explosion-proof solenoid valve product:

The explosion-proof solenoid valve can be divided into two structures based on the energized state: normally open and normally closed. The normally closed direct-acting explosion-proof solenoid valve is in the closed state when the power is off. When the coil is energized, the valve core is subjected to strong electromagnetic force due to electromagnetic induction, and the valve core overcomes the spring force and engages with the valve disc at the moment of opening the valve body, allowing the medium to flow. When the coil of the direct-acting explosion-proof solenoid valve is de-energized, the electromagnetic force disappears instantly, and the moving iron core is reset under the action of the spring force. The valve closes, and the medium stops flowing. The direct-acting explosion-proof solenoid valve has a simple structure and reliable operation, and can work normally even under zero pressure difference and micro vacuum conditions.

III. Main features of the threaded explosion-proof solenoid valve product:

1. The working life of the explosion-proof solenoid valve is long.

2. Working mode of the explosion-proof solenoid valve: it is divided into three types: long-term working mode, repeated short-term working mode, and short-term working mode. The explosion-proof solenoid valve is of the long-term working mode, that is, the coil is allowed to work continuously under power. For situations where the valve is open for a short time only during long periods of opening, a normally open solenoid valve should be selected. When short-term working mode is used and the batch size is large, special orders can be made to reduce power consumption.

3. Working frequency of the explosion-proof solenoid valve: when the action frequency is high, the structure should preferably be a direct-acting solenoid valve, and the power supply should preferably be AC.

The threaded explosion-proof solenoid valve is widely used in environments where flammable and explosive media are present, as well as for the automatic switching of pipeline media in areas with explosive hazards; such as natural gas, gas, liquefied gas, etc. or other media. It is applicable to aerospace, nuclear industry, shipbuilding, petrochemical, power, energy, urban fire protection, gas supply, water supply, etc.

Packing of Standard Packing:

Typical bulk packaging includes palletized plastic 5 gallon/25 kg. pails, fiber and steel drums to 1 ton super sacks in full container (FCL) or truck load (T/L) quantities. Research and sample quantities and hygroscopic, oxidizing or other air sensitive materials may be packaged under argon or vacuum. Solutions are packaged in polypropylene, plastic or glass jars up to palletized 470 gallon liquid totes Special package is available on request. E FORUs’  is carefully handled to minimize damage during storage and transportation and to preserve the quality of our products in their original condition.
