Product Code : VF--DCCC-DC68-CU
Product Specifications:
Product Specifications: DN1 - DN600
Applicable Media: Petroleum, crude oil, butter, glue, lubricating oil, etc. (high-viscosity media)
Control Mode: Normally Closed, Normally Open
Valve Body Material: Cast iron, cast steel, stainless steel (Cast iron and cast steel bodies cannot be used in corrosive fluids)
Power Supply Voltage: DC12 - 220V, AC24 - 380V
Media Temperature: -200℃ ~ +450℃
Media Viscosity: Greater than 50 Cst
Connection Method: Flange, welding, internal thread (external thread and special interfaces can be customized or equipped with adapters)
Protection Performance: Dust-proof, waterproof, explosion-proof. Choose according to working conditions
Connection Method: Socket type; lead-in type; plug type
Leakage: Zero
Please contact us if you need customized services. We will contact you with the price and availability in 24 hours.
| Product | Product Code | Purity | Size | Contact Us |
Structural features:
Pilot-type structure, with a stainless steel piston as the valve core;
High sealing performance and long service life;
There is no direct friction between the piston and the metal valve chamber;
Special large-power coil, less prone to burning out, and still sensitive during long-term operation;
Zero leakage, with a service life of over 100,000 times;
Working principle:
Normally closed type: When the coil is energized, the pilot valve core is attracted, the pilot hole opens, the upper chamber of the valve is relieved of pressure, and the piston is pushed by the medium pressure in the lower chamber, and the electromagnetic valve opens; when the coil is de-energized, the pilot valve core is reset by the spring, the pilot hole closes, the upper chamber of the valve is pressurized by the piston throttling hole and the push force of the reset spring, and the electromagnetic valve closes.
Normally open type: When the coil is energized, the pilot hole is closed, the upper chamber of the valve is pressurized by the piston throttling hole and the push force of the reset spring, and the electromagnetic valve closes; when the coil is de-energized, the pilot valve core is reset by the spring, the pilot hole opens, the upper chamber of the valve is relieved of pressure, and the piston is pushed by the medium pressure in the lower chamber, and the electromagnetic valve opens.
Note:
1. The outlet end has a higher pressure than the inlet end. The medium will reverse and conduct. A check valve can be installed or a valve with built-in check function can be customized.
2. Before stopping the use of the electromagnetic valve, the internal residual medium of the valve must be cleaned.
Product application:
It is widely used in the automatic control systems of pipelines for media with high viscosity (greater than 50 Cst) in industries such as metallurgy, petrochemicals, pharmaceuticals, tobacco, food and medical care, scientific research, energy conservation, and gel production.
