3-inch - 2500LB forged steel high-pressure flanged stop valve, high-pressure flanged stop valve

3-inch - 2500LB forged steel high-pressure flange stop valve body cover connection design form

I. Body cover bolt connection forged steel stop valve. Valves designed with this connection form use bolts to connect the valve body and valve cover, and adopt spiral wound gaskets for sealing. The advantage is that it is convenient for maintenance during use;

II. Body cover welding connection forged steel stop valve. Valves designed with this connection form have the valve body and valve cover fully welded for sealing. The advantage is no external leakage;

Forged steel stop valve design and application specification:

1. Design and manufacture: According to ANSI B16.34; API602; BS5352

2. Connection end dimensions:

(1) The size of the socket and plug holes shall follow ANSI B16.11; JIS B2306

(2) The thread end dimensions shall comply with ANSI B1.20.1 and BS21; ISO’/,; JIS BO203

3. Valve inspection and testing; in accordance with API598

4. Materials: in accordance with AISI/ASTM standards

5. Main materials: AI05; F11; F22; 304; 304L; 316; 316L; LF2...

6. Marking according to MSS-SP-25

3-inch - 2500LB forged steel high-pressure flanged stop valve structure

1. Full diameter or reduced diameter

2. Open stem bracket type

3. Self-centering pressure plate and pressure sleeve type

4. Bolted connection, fully welded sealing connection, and internal pressure self-tightening type valve cover

5. Integral upper sealing seat

6. The valve disc can be transformed into throttle type, needle type, ball type and check type

Scope of Application

Urban construction, chemical industry, metallurgy, petroleum, pharmaceuticals, food, beverages, environmental protection

Scope of Application

Urban construction, chemical industry, metallurgy, petroleum, pharmaceuticals, food, beverages, environmental protection
