Product Code : VF--ZCC-237-CU
Specification: DN100 - DN800
Pressure: 1.6Mpa - 32Mpa (150LB - 600LB) 5k - 63k
Connection type: Flange connection
Applicable media: Water, oil products, steam, nitric acid, acetic acid
Valve body material: Copper, cast iron, cast steel, carbon steel, WCB, WC6, WC9, 20#, 25#, forged steel, A105, F11, F22, stainless steel, 304, 304L, 316, 316L, chromium-molybdenum steel, low-temperature steel, titanium alloy steel, etc.
Working pressure: 1.0Mpa - 50.0Mpa.
Working temperature: -196℃ - 650℃.
Connection method: Internal thread, external thread, flange, welding, butt welding, socket welding, sleeve fitting, clamp.
Drive method: Manual, pneumatic, hydraulic, electric.
Product application: Umbrella gear stop valves are widely used in municipal construction, agricultural water conservancy, thermal power generation, petrochemicals, metallurgy and mining, fire protection and environmental protection, food, shipping, medicine and light textile, etc. in various fields.
J541Y, J541H Umbrella Gear Stop Valve Design Specifications:
1. Design and manufacture in accordance with GB12235-89
2. Structural length in accordance with GB12221-89
3. Flange dimensions in accordance with JB/G79-94 4. Valve inspection and testing shall be in accordance with GB13927
Please contact us if you need customized services. We will contact you with the price and availability in 24 hours.
| Product | Product Code | Purity | Size | Contact Us |
J541H/Y/W bevel gear Globe Valve
The opening and closing parts of J541H/Y/W bevel gear globe valve are stop-shaped valves, the sealing surface is flat or conical, and the valves move in a straight line along the center line of the fluid. The move
ment form of the valve stem, there are lifting rod type (the valve stem is lifted, the handwheel is not lifted), and there are lifting and rotating rod type (the handwheel and the valve stem are rotated and lifted together, and the nut is located on the valve body). The cut-off valve is only suitable for full opening and full closing, and is not allowed to adjust and throttle.
Feature Introduction
(1) The structure is simpler than that of a gate valve, and both manufacturing and maintenance are more convenient.
(2) The sealing surface is less prone to wear and scratches, with good sealing performance. During opening and closing, there is no relative sliding between the valve disc and the sealing surface of the valve body, so the wear and scratches are not severe, and the sealing performance is good with a long service life.
(3) During opening and closing, the stroke of the valve disc is small, so the height of the globe valve is smaller than that of the gate valve, but the structural length is longer than that of the gate valve.
(4) The opening and closing force is large, and it is more strenuous to open and close. The opening and closing time is longer.
(5) High fluid resistance. Due to the tortuous path of the medium in the valve body, the fluid resistance is high, resulting in significant power consumption.
(6) Flow direction of the medium
When the nominal pressure PN is ≤ 16 MPa, the normal flow direction is upward from the bottom of the valve disc; when the nominal pressure PN is ≥ 20 MPa, the reverse flow direction is downward from the top of the valve disc. This is to enhance the sealing performance. During use, the medium of the stop valve can only flow in one direction and cannot change the flow direction.
(7) When fully open, the valve disc is often subject to erosion.
Product application: Umbrella gear stop valves are widely used in municipal construction, agricultural water conservancy, thermal power generation, petrochemicals, metallurgy and mining, fire protection and environmental protection, food, shipping, medicine and light textile, etc. in various fields.
