Product Code : VF--ZCC-243-CU
Product name: Y-type stop valve
Product model: J65Y
Nominal diameter; DN15 - DN300
Structural form; Gate type
Nominal pressure; 1500LB - 2500LB
Connection method; Welding, Flange
Applicable temperature; -29ºC - +550ºC
Main materials: A105, F11, F22, F316, F91, F92Main materials: A105, F11, F22, F316, F91, F92
Drive method; Handwheel, Bevel gear, Electric
Valve body material; Forged steel, Carbon steel, Chromium-molybdenum-vanadium steel, Stainless steel
Applicable medium; Water, Oil, Steam, Gas
1. The design and manufacture of the valve comply with the provisions of API 623-2013, JIS E101 and NB/T 47044-2014, etc.
2. The valve test complies with the provisions of API 598-2009, etc.
3. Structural length complies with the provisions of ASME B16.10-2009, JIS E101 and NB/T 47044-2014, or according to enterprise standards or the dimensions provided by the user.
4. Welding bevels comply with the provisions of ASEM B16.25-2012, GB/T 12224-2005, JB/T 3595-2002, NB/T 47044-2014 and the power industry management standard 78DG, or the dimensions provided by the user.
5. Pressure and temperature rating values comply with the provisions of ASME B16.34-2013, etc.
Please contact us if you need customized services. We will contact you with the price and availability in 24 hours.
| Product | Product Code | Purity | Size | Contact Us |
The valve body and valve cover of the J65Y-Y type stop valve are integrally forged, featuring high strength, an attractive appearance, and reliable material. The middle chamber adopts a self-sealing structure, and the higher the pressure, the better the sealing performance. The unique stainless steel self-sealing ring is easy to disassemble and install, with reliable sealing. The surface of the valve stem is treated with super strong and dense wear-resistant treatment, which is resistant to wear and corrosion, and has low friction during opening and closing, ensuring that the product is free from leakage.
1. The design and manufacture of the valve comply with the provisions of API 623-2013, JIS E101 and NB/T 47044-2014, etc.
2. The valve tests are conducted in accordance with the provisions of API 598-2009, etc.
3. The structural length is in accordance with the provisions of ASME B16.10-2009, JIS E101 and NB/T 47044-2014, or according to enterprise standards or the dimensions provided by the user.
4. The welding bevels are in accordance with the provisions of ASEM B16.25-2012, GB/T 12224-2005, JB/T 3595-2002, NB/T 47044-2014 and the management standards of the power industry 78DG, or the dimensions provided by the user.
5. The rated pressure and temperature values are in accordance with the provisions of ASME B16.34-2013, etc.
The valve body and valve cover of the J65Y-Y type stop valve are integrally forged, featuring high strength, an attractive design and reliable material. The middle chamber adopts a self-sealing structure, and the higher the pressure, the better the sealing performance.
