Product Code : VF--ZHCC-ZH95-CU
Product Name: Slide Track Ball-Type Check Valve
Model: HQ41X
Bore: DN40 - 500
Pressure: PN1.0 - 6.4MPa
Material: Cast iron, carbon steel, stainless steel, etc.
The slide track ball-type check valve has excellent sealing performance, is noiseless when closing, and does not cause water hammer. The valve body adopts a full water flow channel, with large flow rate and low flow resistance. The water head loss is 50% less than that of the swing type. It can be installed horizontally or vertically and is suitable for water supply networks in cold water, hot water, industrial and domestic sewage systems.
Please contact us if you need customized services. We will contact you with the price and availability in 24 hours.
| Product | Product Code | Purity | Size | Contact Us |
Product Overview of Sliding Ball-Type Check Valve:
The sliding ball-type check valve is suitable for installation at the outlet of a submersible sewage pump. It uses a rubber-covered ball as the valve disc. Under the action of the medium, the ball can roll up and down on the integral sliding track within the valve body, thereby opening or closing the valve to prevent backflow of water and water hammer damage to the pump. The ball is covered with a soft sealing layer. The flow channel formed by the inlet and outlet and the sliding track form a 30° angle. The valve cover surface inside the valve body has an arc-shaped groove that fits the ball, and the valve seat adopts an inwardly recessed structure, with a sealing pad inside. The outer surface of the ball and the valve seat both have soft seals, enhancing the sealing performance. Additionally, the sliding track of the ball is designed at a 30° angle to the flow channel, allowing the fluid entering the inlet to easily push the ball to roll along the sliding track into the arc-shaped groove on the inner side of the valve cover, accelerating the flow rate of the fluid. Opening and closing the valve is very convenient.
Advantages of the sliding ball type check valve product:
The sliding ball type check valve product has excellent sealing performance, silent closing, and does not cause water hammer. The valve body adopts a full flow channel, with large flow rate and low flow resistance. The water head loss is 50% less than that of the swing type. It can be installed horizontally or vertically and is suitable for water supply networks in cold water, hot water, industrial and domestic sewage systems.
Application:
The sliding ball type check valve has excellent sealing performance, silent closing, and does not cause water hammer. The valve body adopts a full-flow channel, featuring large flow rate and low flow resistance. The water head loss is 50% less than that of the swing type. It can be installed horizontally or vertically and is suitable for water supply networks in cold water, hot water, industrial and domestic sewage systems.
Packing of Standard Packing:
Typical bulk packaging includes palletized plastic 5 gallon/25 kg. pails, fiber and steel drums to 1 ton super sacks in full container (FCL) or truck load (T/L) quantities. Research and sample quantities and hygroscopic, oxidizing or other air sensitive materials may be packaged under argon or vacuum. Solutions are packaged in polypropylene, plastic or glass jars up to palletized 470 gallon liquid totes Special package is available on request. E FORUs’ is carefully handled to minimize damage during storage and transportation and to preserve the quality of our products in their original condition
