Product Code : VF--DCCC-DC70-CU
Product Specifications:
Product Specifications: DN15 - DN300
Applicable Media: Gasoline, Diesel, Alcohols, etc.
Control Mode: Normally Closed
Valve Body Material: Cast Steel Body, Stainless Steel (The cast steel body cannot be used for corrosive fluids)
Power Supply Voltage: DC12 - 127V, AC36 - 380V
Media Temperature: -20 ~ (+120, +200, +300, +400, +500, +600)℃
Connection Method: Flange, Welding, Internal Thread (External Thread and Special Interfaces can be customized or equipped with adapters)
Media Viscosity: Less than 50 Cst (Greater than this requires customization)
Protection Performance: Dustproof, Waterproof, Explosion-proof. Choose according to working conditions
Connection Method: Terminal Block Type; Lead-in Type; Plug Type
Leakage: Zero
Please contact us if you need customized services. We will contact you with the price and availability in 24 hours.
| Product | Product Code | Purity | Size | Contact Us |
Product Application:
It is mainly used in pipeline automation control systems for industries such as military, aerospace, shipbuilding, nuclear industry, petrochemicals, power, chemical engineering, machinery, scientific research, water supply and drainage, fire protection equipment, food and medical equipment, landscape sprinkler systems, fueling machines, etc. Its main function is to reduce pipeline vibration when the solenoid valve is opened and closed, and to precisely inject the pipeline medium flow.
Structural Features:
Pilot-type structure, the valve core is a stainless steel piston, and the piston ring will not be stuck by the medium;
High dynamic sealing performance and long service life;
The piston does not have direct friction with the metal valve cavity, and there is no restriction on the installation direction of the valve body;
Special coil, less prone to burning out, and it can still operate sensitively when restarted after a long stop;
Service life exceeds 100,000 times.
Working Principle:
It adopts a double-valve body and dual-flow design. When the solenoid valve is opened, the small valve is opened first, followed by the large valve; when closing, the large valve is closed first, followed by the small valve. The large valve realizes rapid flow, and the small valve achieves precise flow.
Product application:
It is mainly used in pipeline automation control systems for industries such as military, aerospace, shipbuilding, nuclear industry, petrochemicals, power, chemical engineering, machinery, scientific research, water supply and drainage, fire protection equipment, food and medical equipment, landscape sprinkler systems, fueling machines, etc. Its main function is to reduce pipeline vibration when the solenoid valve is opened and closed, and to achieve precise injection of pipeline medium flow.
