Product Code : VF--DCCC-DC69-CU
Product Specifications:
Product Specifications: DN1 - DN600
Applicable Media: Air, water, oil, corrosive fluids, etc.
Control Mode: Normally Closed, Normally Open, Self-Preserving
Valve Body Material: Cast steel, brass, aluminum, stainless steel (cast steel cannot be used for corrosive fluids)
Power Supply Voltage: DC12 - 220V, AC24 - 380V
Media Temperature: -60 ~ (+120, +200, +250)℃
Connection Method: Flange, Welding, Internal Thread (External Thread and Special Interfaces can be customized or equipped with adapters)
Media Viscosity: Less than 50 Cst (Greater than this requires customization)
Protection Performance: Dust-proof, Water-proof, Explosion-proof. Choose according to working conditions
Connection Method: Terminal Block Type; Lead-in Type; Plug Type
Leakage: Zero
Please contact us if you need customized services. We will contact you with the price and availability in 24 hours.
| Product | Product Code | Purity | Size | Contact Us |
Structural features:
Adapted to the characteristics of each series of solenoid valves;
When the solenoid valve coil is de-energized or burned out, the handle can be used to open or close the valve;
Easy to operate and stable in performance;
Stainless steel piston structure, good sealing, quick opening and closing;
Special coil, less prone to burning out;
Working principle:
Normally closed type: When the coil is not energized or burned out, the valve can be opened manually. However, when the manual operation is in the open state, the valve cannot be automatically controlled.
Normally open type: When the coil is not energized or burned out, the valve can be closed manually. However, when the manual operation is in the closed state, the valve cannot be automatically controlled, and neither the coil energization nor de-energization can open the valve.
Product Application:
It is widely used in military industry, aerospace, shipbuilding industry, nuclear industry, petrochemical industry, power industry, chemical industry, light industry, machinery industry, scientific research, drying equipment, boilers, water supply and drainage systems, food and medical equipment, cleaning equipment, etc. especially in the field of fire protection equipment. It has both electric and manual control methods. By utilizing advanced technologies such as temperature measurement and control technology, infrared sensing technology, imaging sensing technology, and digital technology, it enables remote control and automatic fire extinguishing.
Packing of Standard Packing:
Typical bulk packaging includes palletized plastic 5 gallon/25 kg. pails, fiber and steel drums to 1 ton super sacks in full container (FCL) or truck load (T/L) quantities. Research and sample quantities and hygroscopic, oxidizing or other air sensitive materials may be packaged under argon or vacuum. Solutions are packaged in polypropylene, plastic or glass jars up to palletized 470 gallon liquid totes Special package is available on request. E FORUs’ is carefully handled to minimize damage during storage and transportation and to preserve the quality of our products in their original condition.
