Product Code : VF--DCCC-DC45-CU
Principle structure: Fluorine-coated piston type
Operating temperature range: -10 to -80℃
Control mode: Normally closed type, normally open type
Fluid range: Concentrated acids, bases, salts, oxidants, reductants, organic solvents, etc. of alkaline liquids and gases.
Fluid temperature range: -50℃ to 150℃
Standard voltage: AC 220V, DC 24V (Other voltages can be customized)
Valve body material: Carbon steel inner lining fluoroplastic, stainless steel inner lining fluoroplastic
Valve core material: PTFE (Polytetrafluoroethylene, commonly known as the "King of Plastics")
Electrical connection: Junction box (2 non-polarity power supply terminals, 1 grounding terminal)
Protection level: International standard IP54
Explosion-proof level: DIIBT3, DIIBT4, DIIBT5, DIIBT6
Fluorine-coated solenoid valve, fluorine-coated inner valve. Ideal choice for industries such as chemical engineering, petroleum, medicine, food, steel smelting, coking, papermaking, ships, hydropower, etc. The product features a novel structure, unique process, wide range of strength and high temperature adaptability, long service life, etc.
Please contact us if you need customized services. We will contact you with the price and availability in 24 hours.
| Product | Product Code | Purity | Size | Contact Us |
The fluorine-coated electromagnetic valve is suitable for resisting strong corrosive media. The inner coating is applied to the inner walls of cast steel, carbon steel, and stainless steel valve bodies or pipe fittings, as well as the surfaces of valve internals. It can be used in media such as acids, alkalis, salts, oxidants, reductants, solvents, etc. The fluorine-coated electromagnetic valve is chosen by industries such as chemical engineering, petroleum, steel smelting, coking, papermaking, hydropower, etc. The product of the fluorine-coated electromagnetic valve has the characteristics of wide adaptability in structure, process, and temperature, as well as long service life.
Features of Fluorine-Coated Electromagnetic Valves
The fluorine-coated electromagnetic valve is a corrosion-resistant internal fluorine-coated electromagnetic valve product. The sealing components are resistant to corrosion. The fluorine-coated electromagnetic valve can withstand strong acids, strong bases, strong oxidants and solvents, with a usage temperature of less than 150℃. It is applied in automatic control systems of petrochemicals, power equipment, machinery, chemical reagent factories, chemical analysis instruments, sewage treatment equipment, scientific research instruments, etc.
Fluorine-coated solenoid valve, fluorine-coated inner valve. Ideal choice for industries such as chemical, petroleum, medicine, food, steel smelting, coking, papermaking, ships, hydropower, etc. The product features a novel structure, unique process, wide range of strength and high temperature adaptability, long service life, etc.
Packing of Standard Packing:
Typical bulk packaging includes palletized plastic 5 gallon/25 kg. pails, fiber and steel drums to 1 ton super sacks in full container (FCL) or truck load (T/L) quantities. Research and sample quantities and hygroscopic, oxidizing or other air sensitive materials may be packaged under argon or vacuum. Solutions are packaged in polypropylene, plastic or glass jars up to palletized 470 gallon liquid totes Special package is available on request. E FORUs’ is carefully handled to minimize damage during storage and transportation and to preserve the quality of our products in their original condition.
