30D13R self-operated pressure control valve with pilot device (pre-valve control),Self-operated pressure control valve with pilot device, self-operated pressure control valve, 30D13 control valve

The 30D13 self-operated pressure control valve with a pilot device (pressure control before the valve) consists of a control valve, an actuator, and a pilot device with a set pressure. It is suitable for non-corrosive liquids, gases, and vapors. It functions as a pressure differential control device in the system piping. When the pressure before the valve increases, the control valve opens.

Characteristics of the valve internals:

1. Built-in bellows with a pressure balancing structure, featuring high sensitivity.

2. Compact structure, reliable performance, and maintenance-free.

3. Adopting standard modular design.

4. Through combinations, multiple control functions can be achieved.

Valve body type: Straight-through type

Valve cover form: Standard type

Heat dissipation type

Flow characteristic: Quick opening

The 30D13 self-operated pressure control valve with a pilot device (pressure control before the valve) consists of a control valve, an actuator and a pilot device with a set pressure. When the pressure before the valve increases, the control valve opens.
