Product Code : VF--ZHCC-ZH74-CU
Bore range: NPS 3" to 8" (DN80 to DN200)
Pressure rating: ASME CLASS 150 - 900 (PN16 - PN150)
Main materials: carbon steel, alloy steel, etc.
Connection method: Flange end, butt welding end
Operation mode: Pneumatic, electric, etc.
Application scope: Thermal power industry
Please contact us if you need customized services. We will contact you with the price and availability in 24 hours.
| Product | Product Code | Purity | Size | Contact Us |
The high-pressure drain valve is applied in the condensate water system of thermal power plants, as well as being used as a high-pressure drain valve, a minimum flow recirculation regulating valve for the condensate pump, an oxygen remover water level regulating valve, and a condenser makeup water regulating valve. The sleeve three-stage throttling method involves gradually expanding the throttling area of the channels. This design is suitable for the requirement of increasing the volume of saturated water vaporization and helps to reduce the flow velocity.
Reduce the erosion of the fluid on the internal components of the valve.
The fluid throttling surface is separated from the sealing surface. The inner components of the valve have undergone surface hardening treatment, which results in high hardness, resistance to erosion, and long service life.
The regulating valve is tightly closed, and the leakage standard of the metal valve seat can reach Level IV of ANSI B16.104-1976.
The internal components of the valve adopt a pressure-balancing structure, which reduces the volume of the actuator.
The high-pressure drain valve is applied in the condensate water system of thermal power plants, as well as being used as a high-pressure drain valve, a minimum flow recirculation regulating valve for the condensate pump, an oxygen remover water level regulating valve, and a condenser makeup water regulating valve.
