Product Code : VF--ZHCC-ZH63-CU
Nominal diameter DN; 20 - 20
Flow characteristics: Straight line; Straight line; Linear percentage
Operating mode: Air-closing type (B), Air-opening type (K)
Spring pressure range (KPa): Standard signal: 20 - 100; Other signals: 40 - 200; 20 - 60; 60 - 10
Please contact us if you need customized services. We will contact you with the price and availability in 24 hours.
| Product | Product Code | Purity | Size | Contact Us |
I. Pneumatic Low-Temperature Single-Seat Control Valve - Overview
The ZMAP-16D pneumatic low-temperature single-seat control valve is a variant of the single-seat and double-seat types. The difference from normal temperature is that it adopts a long-neck type upper valve cover, allowing the packing to work at normal temperature. It is suitable for regulating media (such as liquid oxygen, liquid nitrogen, etc.) under low-temperature conditions of -60 to -250 degrees Celsius. To ensure the accuracy of regulation, a positioner must be used.
II. Pneumatic Low-Temperature Single-Seat Control Valve - Structural Principle
The pneumatic low-temperature control valve consists of a pneumatic diaphragm actuator and a low-temperature-resistant single or double-seat valve. The signal pressure from the regulator is input into the air chamber of the pneumatic diaphragm actuator, generating a thrust. This thrust is transmitted through the connecting rods to the valve core, and the change in the position of the valve core results in a change in the flow cross-section of the valve, thereby achieving the regulation of the medium flow.
The ZMAP-16D pneumatic low-temperature single-seat regulating valve is a variant of the single-seat and double-seat valves. The difference from normal temperature is that it adopts a long-neck type upper valve cover, allowing the packing to work at normal temperature. It is suitable for regulating media (such as liquid oxygen, liquid nitrogen, etc.) under low-temperature conditions of -60 to -250℃. To ensure the regulating accuracy, a positioner must be used.
